High Level Digital Communication Trainer

GMSK Modulator:

Clock: 600Hz ~ 2kHz

Clock Mode: TTL Level

Data rate: 300Hz~1kHz

Data mode: TTL Level

Career frequency: 10.7 MHz

Modulation Index: 0.5

GMSK Demodulator:

Clock: 600Hz ~ 2kHz

Clock Mode: TTL Level

Data rate: 300Hz~1kHz

Data mode: TTL Level

Career frequency: 10.7 MHz

Modulation Index: 0.5

Function Generator and DC Power Supply:

Waveforms: Sine, Triangle, Square, TTL Pulse

Amplitude: 10Vpp

Impedance: 50Ω, ± 10%

Duty Control: 30% ~ 60%

Display: 6-Digit LED

Frequency Range: 10Hz ~ 100 kHz (4 Ranges)

Frequency Range: 100Hz ~ 1 MHz (4 Ranges)

Constant Voltage Output: ± 5V, ± 12V

Variable Voltage Output: 0V ~ ± 15V

Power source: 220~230V AC, 50Hz, 1 Phase
