Open-Type Refrigeration Compressor

Type: Open-type (open-drive) reciprocating compressor, belt-driven, drive shaft passes through a shaft seal.
Capacity: Minimum 1/2 hp (0.37 kW)
Voltage: 220V AC / 50-60Hz / Single phase
Displacement: Greater than 20 cubic centimeters per revolution.
Drive Motor: Greater than 1/2 hp (0.37 kW), 220-240 volts, single phase, 50 Hz
Intake/Exhaust: Intake and exhaust service valves or manifold assemblies are provided and installed, each with a 1/4-inch SAE (7/16-inch UNF) pressure gauge interface. Piping connections conform to ISO and CE standards.
Installation: The compressor and drive motor are mounted on the same base, including pulleys, V-belt, belt guard, and mounting bracket; if a clutch pulley is included, its DC power supply and switch are also included.
Lubrication:
- Oil Type: Polyol Ester Synthetic Refrigeration Oil (POE)
- ISO Viscosity Grade: ISO VG68
- Recommended Grade: Emkarate RL68H / Bitzer BSE68
- Filling Capacity: 4 liters
