Universal Junction Box

I. Product Description

This tool set is specifically designed for the teaching and learning of new energy vehicle technology, making it an essential part of any training or technical program focused on electric and hybrid vehicles.

II. Technical Requirements

• T-Shaped Wires: The tool set includes various specifications of "T"-shaped wires, designed to enable plug-in measurements for all fuses, relays, sensors, and actuators in the car competition system. The wires are capable of handling sufficient current and are built for repeated plug-in use.
• Probe: Designed for easy measurement without causing damage to the original vehicle wiring harness, ensuring safe and reliable operation.
• Alligator Clip: Provides a temporary circuit connection with a serrated clamp for secure attachment to components. The personalized insulation design ensures safer operation by preventing accidental contact.
• Adjustable Resistance: This feature allows users to simulate virtual connection faults and also protects electrical components from damage.
• Test Pen Head: Equipped with PVC silicone wire, the test pen provides high sensitivity, accuracy, and durability, ensuring reliable results. It can be directly connected to a power meter for effective diagnostics.
• Three-Way Connector: Offers high measurement performance and ease of use, making it ideal for various diagnostic tasks.
• Test Light: Used to quickly verify whether a device is energized. It features high insulation performance to ensure safety during testing.
• Test Line: Designed to support plug-in measurements for various vehicle components such as fuses, relays, and sensors, making it versatile for vehicle diagnostics.

III. Supporting Teaching Resources:

Free training and product manuals are provided.
