Automatic drain valve anatomical model

Product Overview:

This automatic drain valve dissection model is a professional teaching and training device designed for vocational schools, enterprise skills training centers, and pneumatic/hydraulic system laboratories. It uses a real industrial-grade automatic drain valve (float type/electronic timing type/differential pressure type) as a prototype, and through precise cross-section and structural solidification, it intuitively presents the internal core components and operating mechanisms. It can be used for structural understanding, principle demonstration, disassembly and assembly training, and fault diagnosis teaching in compressed air systems, refrigeration equipment, pressure vessels, and related majors, significantly reducing the understanding threshold of abstract knowledge and improving the efficiency of practical teaching.

Features:
1. The dissection uses an automatic drain valve assembly (with complete accessories), with all parts present, comprehensively showcasing the internal and external structure of the assembly.

2. Through dissection and different colors sprayed on each section, the mechanical structure of the internal and external components and their assembly relationships are clearly displayed.

3. The equipment base frame (with shock-absorbing rubber pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The shock-absorbing rubber pads are fixed to the base with M6*4 screws.

Training Project:

I. Overall Training Objectives

Understand the structure, installation location, and function of automatic drain valves.

Master the working principle and operation process of drain valves.

Be able to disassemble, assemble, inspect, diagnose faults, and perform simulated repairs.

Understand the practical applications of drain valves in air compressor, air tank, and refrigerated dryer systems.

II. Training Project Content

Project 1: Structural Understanding and Component Identification

Project 2: Dynamic Demonstration of Working Principle

Project 3: Standardized Disassembly and Assembly Training

Project 4: Component Inspection and Quality Judgment

Project 6: System Application and Installation Training
