Chassis Teaching and Training System (2)

Product Introduction:

The automotive chassis teaching and training equipment is based on the various systems of a B5 automotive chassis, fully demonstrating the structural composition of each system.

It includes the front and rear suspension systems, steering system, transmission system, manual transmission and gear shifting mechanism, braking system, and a movable platform with casters.

It is suitable for schools' teaching needs for theoretical and practical training in chassis systems.

Features:

1. Installs realistic automotive chassis systems (including front and rear suspension systems, steering system, transmission system, manual transmission and gear shifting mechanism, and braking system), fully demonstrating the structural composition of each system.

2. Allows for realistic demonstration and disassembly/assembly training of various automotive chassis systems.

3. The dissected transmission can be dynamically demonstrated and tested. With power input from the geared motor, the transmission can perform simulated gear shifting operations and dynamic tests. Slow-speed driving demonstration with all four wheels in contact with the ground is also possible.

4. A motor-driven power steering pump realistically demonstrates the power steering process.

5. The training platform base is constructed of welded steel structure with a powder-coated surface. It features self-locking casters for easy movement, safety, reliability, and durability.

Technical Specifications:

Dimensions: Approx. 2600×1700×1500mm (L×W×H)

Power Supply: 220V

Operating Temperature: -40℃～+50℃

Main Unit: Original Vehicle Unit

Motor: 220V/250W 15 rpm

Residual Current Circuit Breaker: DZ47LE-32

Color: 7032

Steel Pipe: 40*40*3mm

Cast: 100*50mm
