Comprehensive New Energy Vehicle Diagnostic System

I. Product Functions

• Vehicle Detection
  Supports full-system and full-function detection for new energy vehicle models. This includes code reading, code clearing, data flow reading, action testing, special functions, and more. The system also supports remote collaboration, super remote, and trial feedback functionalities.
• Battery Pack Detection
  Supports battery pack detection for passenger cars, commercial vehicles, and various battery brands. It can read key data such as SOC/SOH, single/module voltage, temperature, battery pack status, and fault information. It also automatically calculates total voltage, pressure difference, and key indicators, marking abnormal data automatically.
• Maintenance Function
  Supports offline testing for DC-DC converters, OBC on-board chargers, air-conditioning compressors, 48V mild hybrid components, and more. Additionally, it supports maintenance tasks like light reset, throttle matching, brake pad replacement, steering angle reset, anti-theft matching, ABS exhaust, injector coding, DPF regeneration, sunroof initialization, and gearbox matching.
• Anti-Theft Matching
  Includes vehicle anti-theft matching, anti-theft chip reading/writing, anti-theft ECU reading/writing, key matching, and other related functions.
• ADAS Calibration
  Supports ADAS system calibration for many vehicles in Europe, America, Asia, and China. Compatible with ADAS PRO+, ADAS MOBILE, ADAS LITE, ADAS RADAR 3IN1, and other ADAS devices.
• User Center
  Allows account registration, viewing connected devices, and activating diagnostic connectors.
• Upgrade Center
  Enables online software upgrades for applications, vehicle software, and firmware. Also includes APP and vehicle software management features.
• Report Center
  Supports viewing and managing reports generated from applications. Reports can be filtered, merged, and combined to create comprehensive reports.
• Tire Equipment Application
  Supports four-wheel alignment and tread detection functions. It can be connected to WA913 and TTM113.
• New Energy Testing Tool Application
  Supports a wide range of new energy testing tools, including balancing tests, wireless balancing, charging/discharging, insulation tests, current clamp, and more.
• System Applications
  Includes apps for camera, gallery, calculator, calendar, email, file management, browser, and system settings.

II. Product Features

• Wide Vehicle Model Coverage
  Supports over 95% of new energy vehicle models, including full-system diagnostics with continuous updates.
• Offline Testing & Maintenance
  Provides offline testing for multiple components and maintenance functions, offering efficient diagnostics.
• Multiple Battery Pack Connection Methods
  Supports four battery pack connection methods, featuring a patented battery pack dedicated connector for high detection efficiency.
• Topology Display
  Displays vehicle topology, clearly showing vehicle communication pathways and rapidly pinpointing fault points.
• Remote Diagnosis Box
  Features a standard remote diagnosis box, supporting super remote diagnosis and independent Wi-Fi communication.
• Customizable AAOS System
  The deep customization of the AAOS system supports split-screen application display, allowing users to access information or consult via WeChat while performing vehicle inspections.
• Multi-Device Intelligent Connection
  Supports integration with multiple diagnostic devices, including four-wheel alignment, tire pattern detection, ADAS, anti-theft, and new energy testing/maintenance equipment.
• Multi-Device Report Merging
  Supports merging reports from multiple devices into a comprehensive report for a complete diagnostic summary.
• Large HD Display
  Equipped with a 13.3-inch high-definition screen (1920×1080), offering a modern design with ultra-light and ultra-thin construction.

III. Product Parameters

1. Host Parameters

• Display: 13.3 inches (1920×1080)
• CPU: 2.0 GHz Octa-Core
• Memory: 8 GB
• Storage: 256 GB
• System: AAOS (Android 10)
• Wi-Fi: 2.4 GHz/5 GHz dual-band Wi-Fi
• Camera: 800W front camera, 1300W rear camera
• Battery: 13600mAh/3.8V
• Interface: USB, Type C, DC-IN, Mini HDMI
• Communication: Wi-Fi, Bluetooth, USB
• Size: 355.4 × 227 × 34.45 mm

2. VCI Parameters

• CPU: Cortex-A7 + Cortex-M7
• Memory: 256 MB
• Storage: 8 GB
• System: Linux
• Display: 3.97 inches, resolution 320×480
• Operating Voltage: DC 9-36V
• Wi-Fi: 2.4 GHz/5 GHz dual-band
• Interface: Type B, RJ45, OBD-II 16, DC-IN
• Communication Method: Local diagnostic mode: Wi-Fi, Bluetooth, USB; Remote diagnosis mode: Ethernet, Wi-Fi
• Dimensions: 192 × 107.2 × 42.5 mm

IV. Supporting Teaching Resources:

Free training, product manual, and operation videos are provided.
