Power windows, central locking, power mirrors

Product Overview:

This training platform is based on real electric vehicle components and demonstrates the working principles and processes of electric vehicle drive systems. For safety reasons, a low-voltage system simulates the operation of a high-voltage system, ensuring human safety.

Main Components:

72V 50Ah lithium iron phosphate battery pack, lithium battery management system module, AC stepper motor, 5KW motor controller, instrument cluster, DC-DC power converter, 7-inch information display, gear switch, on-board charger, charging gun, high-voltage box, rear reduction axle, ignition switch, low-voltage battery, relays, charging plug, maintenance switch, mobile base, etc.

Features:

1. This teaching board includes component names and component lead-out measurement terminals, facilitating more intuitive explanation and measurement analysis by instructors. Multimeters and oscilloscopes can be used to test the resistance and voltage of various electrical components. Students can intuitively compare circuit diagrams and physical components to understand and analyze the working principles of automotive rearview mirror systems, central locking systems, power window systems, and anti-theft systems.

2. This teaching board features a fully functional automotive power window, central locking, and rearview mirror system, demonstrating their structural composition.

3. The teaching board panel is equipped with testing terminals, allowing direct testing of electrical signals (resistance, voltage, current, frequency, waveform signals, etc.) of various circuit components in the rearview mirror, central locking, power window, and anti-theft systems.

4. This teaching board allows operation of the power window, central locking, and rearview mirror switches. It can demonstrate the original vehicle functions of each component of the window system, such as locking/unlocking doors, raising/lowering windows, and adjusting rearview mirrors.

5. This teaching board features fully functional automotive systems, demonstrating the structural composition of the rearview mirror, central locking, power window, and anti-theft systems. The teaching board comes with an instruction manual and related materials.

6. The teaching board panel is made of high-grade aluminum composite panel, which is corrosion-resistant, impact-resistant, stain-resistant, fireproof, and moisture-proof. The surface is treated with a special primer spraying process; the panel is printed with color circuit diagrams that will never fade.

Technical Specifications:

Dimensions: 1000 × 600 × 1700mm (Length × Width × Height)

Operating Power Supply: DC 12V2

Operating Temperature: -40℃ ~ +50℃
