High-voltage connector plug-in training station

Product Overview:

The high-voltage connector of electric vehicles is selected for Geely, BAIC New Energy, Yutong Bus, etc.; Installed on the special power battery pack box, through the students' hands-on plugging and unplugging, so that the students can master the actual mastery of the high-voltage connector plugging and unplugging operation, as well as the possible consequences of not operating according to the procedure, which is the necessary basic essentials for the safe operation of new energy electric vehicles.

Features:

The high-voltage connector of new energy vehicles is used and installed on the special power battery pack box, and the trainees carry out repeated plugging and unplugging of the high-voltage connector in the absence of electricity. The high-voltage connector plug and socket are matched with the same cable as the power battery pack, and the electrical connection method is the same as that of the actual car, and the name is marked. The panel draws the plugging and unplugging methods and precautions for each high-voltage connector. Supporting to provide maintenance switch plugging and unplugging methods, discharge positive and negative plug-in plug-in methods, charging positive and negative plug-in plug-in methods and other auxiliary resources. 4 universal casters with self-locking device are installed at the bottom. The selected mainstream pure electric permanent magnet synchronous motor and controller are connected to the high-voltage cable divided into two sections, one end is fixed with the permanent magnet synchronous motor U/V/W high-voltage interface, and the plug is the same as that of the original car;       The other end is connected with the motor controller, and a high-voltage quick-connect plug is added in the middle, and the plug is equipped with high-voltage interlock, which disconnects the high-voltage interlock connection circuit, and the whole system is powered off, which is convenient for high-voltage interlock circuit control teaching. The detection panel is made of acrylic material, and the surface is treated with a special process of spraying primer; Equipped with a detection terminal with protection function, the name of the detection terminal is silk-screened in white font. Supporting new energy vehicle drive system teaching resource package software V1.0; Three-dimensional animation is used to explain the structural composition and control principle of the drive motor assembly of mainstream new energy vehicles.

Dimensions:

1400×700×1450 (L*W*H) Operating temperature: -20°~+40°
