Digital Communication Trainer

ASK Modulator using XR2206 (Career Signal: 20kHz, Data Rate: 1 kbps)

ASK Modulator using MC1496 (Career Signal: 20kHz~100kHz, Data Rate: 2 kbps)

Asynchronous ASK Demodulator using XR2206 (Career Signal: 20kHz, Data Rate: 200 bps ~1kbps)

Asynchronous ASK Demodulator using MC1496 (Career Signal: 20kHz, Data Rate: 200 bps ~1kbps)

Synchronous ASK Demodulator (Career Signal: 100kHz, Data Rate: 200 bps ~2kbps)

Function Generator and DC Power Supply:

Waveforms: Sine, Triangle, Square, TTL Pulse

Amplitude: 10Vpp

Impedance: 50Ω, ± 10%

Duty Control: 30% ~ 60%

Display: 6-Digit LED

Frequency Range: 10Hz ~ 100 kHz (4 Ranges)

Frequency Range: 100Hz ~ 1 MHz (4 Ranges)

Constant Voltage Output: ± 5V, ± 12V

Variable Voltage Output: 0V ~ ± 15V

Power source: 220~230V AC, 50Hz, 1 Phase

Accessories: Connecting cables, Short jumpers, Adapter and Instruction
