Hydraulic pump anatomical model

Product Overview:

This hydraulic pump anatomical model is based on an industrial-grade standard hydraulic pump. Through high-precision cutting, sectioning, reinforcement, and color separation, it fully preserves the internal structure and assembly relationships. It is specifically designed for teaching, training, demonstration, and skills assessment in mechanical engineering, automotive repair, construction machinery, hydraulics, and pneumatics. The model intuitively displays the internal structure and working process of the hydraulic pump, achieving "theoretical visualization, structural transparency, and dynamic principle," effectively improving teaching effectiveness and training quality.

Features:
1. The model uses a complete hydraulic pump assembly (with all accessories) for dissection, showcasing all components and comprehensively displaying the assembly's internal and external structure.

2. Different colors are used for each section and section, clearly revealing the mechanical structure of the internal and external components and their assembly relationships.

3. The equipment base frame (with anti-vibration pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The anti-vibration pads are fixed to the base with M6*4 screws.

Training Projects:
I. Overall Training Objectives
Master the structural composition, working principle (volume change achieves oil suction and discharge), and differences between types of hydraulic pumps;
Proficiently complete the standardized disassembly and assembly, parts inspection, and assembly debugging of anatomical models;
Identify common faults and master basic troubleshooting methods;
Develop professional habits of safe operation, standardized tool use, and orderly parts management.

II. Modular Training Projects
Project 1: Hydraulic Pump Structure Recognition and Anatomical Observation (Basic Module)

Project 2: Standardized Disassembly and Assembly of Hydraulic Pumps and Clearance Inspection (Core Skills Module)

Project 3: Dynamic Demonstration and Verification of Working Principle (Principle Reinforcement Module)**

Project 4: Simulated Diagnosis and Troubleshooting of Common Faults (Comprehensive Application Module)

Project 5: Hydraulic Pump Selection and System Connection (Extension Module)
