Signal indication system, wiper system

Product Overview:

This equipment uses actual signal and wiper systems as a base, fully demonstrating the composition and operation of automotive lighting, signal, instrument, and wiper systems.

It is suitable for schools' teaching needs in the theory and practical training of automotive lighting, signal, instrument, and wiper systems. This equipment meets the teaching requirements of "five connections and ten links" in automotive vocational education.

Features:

1. A realistic and operable automotive lighting, signal, instrument, and wiper system, fully demonstrating its composition. Operating various electrical switches and buttons realistically demonstrates the operation of the automotive lighting, signal, instrument, and wiper systems.

2. Each electrical component's wiring terminal on the training platform is equipped with a connector. Referring to the accompanying circuit diagram or repair materials, students can connect to the intermediate wiring harness, training their ability to read diagrams and connect terminals.

3. The training platform is equipped with testing terminals, allowing direct testing of electrical signals such as resistance, voltage, current, and frequency signals of various circuit components in the automotive body electrical system on the UV flatbed printing panel.

4. The panel is made of 1.5mm cold-rolled steel sheet, while the base frame is welded steel with a powder-coated finish. It features self-locking casters for easy movement, safety, reliability, and durability. The base includes a 30cm tabletop for placing documents, testing instruments, etc.

Technical Specifications:

Dimensions: 1740 × 650 × 1700mm (Length × Width × Height)

Power Supply: 380V±10% 50Hz

Operating Temperature: -40℃ ~ +50℃
