Air Conditioning Compressor Anatomical Model

Product Overview:

This product is a cross-sectional dissection teaching aid specifically developed for teaching and training automotive air conditioning refrigeration systems. Based on the commonly used swashplate air conditioning compressor in passenger vehicles, it is a 1:1 structural replica of the actual vehicle. Utilizing a longitudinal sectional view and a transparent protective shell, it fully displays the compressor's intake, compression, and exhaust processes, as well as its internal mechanical transmission structure. It is suitable for vocational schools, technical colleges, and automotive repair training institutions for teaching automotive air conditioning system principles, component recognition, fault simulation, and repair training.

Features:
1. Uses an air conditioning compressor assembly (with complete accessories) for dissection, showcasing all components and comprehensively displaying the assembly's internal and external structure.

2. Through dissection and different colors applied to each section, the mechanical structure of the internal and external components and their assembly relationships are clearly visible.

3. The equipment base frame (with anti-vibration pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The anti-vibration pads are fixed to the base with M6*4 screws.

Training Project:

I. Basic Training Information
Training Name: Air Conditioning Compressor Anatomical Model Structure Recognition and Principle Demonstration Training
Applicable Majors: Automotive Application and Maintenance, Automotive Inspection and Repair Technology, New Energy Vehicle Technology

II. Training Objectives
Master the structure, function, and installation location of automotive air conditioning compressors.

Accurately identify the names and functions of each component in a swashplate compressor.

Understand the complete working process of intake → compression → exhaust → circulation.

Demonstrate the working principle of the electromagnetic clutch and the movement law of the swashplate piston.

Be able to diagnose and analyze common compressor faults.

III. Training Content and Operating Steps

1. Structure Recognition and Component Identification

2. Electromagnetic Clutch Working Demonstration

3. Swashplate Compressor Working Principle Demonstration

4. Key Component Inspection

5. Common Fault Simulation and Diagnosis
