Automotive oscilloscope

I. Product Overview

This advanced 8-Channel Oscilloscope is specifically designed for vehicle diagnostics, offering a wide range of automotive testing functions. With over 80 automotive diagnostic functions, including ignition detection, sensor analysis, bus detection, performance testing, and starting and charging circuits, this tool is ideal for both professional technicians and advanced automotive workshops.

It features a video help function, providing online instructional videos that guide users through the diagnostic process. Diagnostic results can be easily generated as reports, printed, or screenshotted with just one key press, offering flexible data-saving options. Additionally, this oscilloscope supports long-term waveform recording, making it ideal for detailed and extended diagnostics.

With the ability to simulate camshaft and crankshaft signals, and support for USB 2.0 plug-and-play connectivity, the device requires no additional power supply, ensuring hassle-free operation and seamless integration into any workshop environment.

II. Key Features

• Bandwidth: 25 MHz
  (Ensures high-frequency signal capture for accurate diagnostics.)
• Oscilloscope Type: USB
  (Plug-and-play USB connectivity for ease of use without the need for additional power sources.)
• Number of Channels: 8
  (Allows simultaneous multi-channel testing, ideal for complex vehicle systems.)
• Sample Rate: 2.4 GS/s
  (Offers fast data capture for precise waveform analysis.)
• Vertical Resolution: 12 bits per channel
  (Provides high precision in signal measurement for detailed analysis.)
• Voltage Range:
  • 10 mV at 5 V / Div (with x1 probes)
  • 100 mV at 50 V / Div (with x10 probes)
  • 10 V to 5000 V / Div (with x1000 probes)
  • 100 V to 50,000 V / Div (with x10,000 probes)
  • 200 mV to 100 V / Div (with x20 probes)
• Coupling: DC
  (Ideal for vehicle diagnostics, allowing measurement of both AC and DC signals.)
• Impedance: 1M ohm
  (Ensures compatibility with most standard automotive test circuits.)
• Programmable Signal Generator:
  (Generates custom signals for testing vehicle systems such as camshaft and crankshaft sensors.)
• Vehicle-Specific Tests:
  (Includes automotive-specific tests like ignition detection, sensor analysis, and circuit performance evaluations.)

III. Additional Features

• Diagnostic Video Help:
  Provides online video tutorials to guide users through the diagnostic process.
• Diagnostic Report Generation:
  Easily generate and save diagnostic reports, which can be printed or stored for later reference.
• Long-Term Waveform Recording:
  Allows extended waveform capture, perfect for monitoring systems over longer durations.
• Camshaft and Crankshaft Signal Simulation:
  Simulates crucial vehicle signals for testing and troubleshooting purposes.
• USB Plug-and-Play Interface:
  Convenient connectivity via USB 2.0, without requiring additional power sources.

IV. Technical Specifications

• Bandwidth: 25 MHz
• Oscilloscope Type: USB
• Number of Channels: 8
• Sample Rate: 2.4 GS/s
• Vertical Resolution: 12 bits/channel
• Voltage Range:
  • 10 mV at 5 V / Div (x1 probe)
  • 100 mV at 50 V / Div (x10 probes)
  • 10 V to 5000 V / Div (x1000 probes)
  • 100 V to 50,000 V / Div (x10,000 probes)
  • 200 mV to 100 V / Div (x20 probes)
• Coupling: DC
• Impedance: 1M ohm
• Programmable Generator: Yes
• Vehicle Tests: Yes

V. Supporting Teaching Resources:

An operation manual is included to ensure smooth installation and operation.
