Car instrument system

Product Overview:

This equipment uses a real automotive instrument system as its foundation, fully demonstrating the system's structure and operation. It is suitable for schools' teaching needs in automotive instrument system theory and maintenance training.

Features:

1. A realistic and operational automotive electronic instrument system, fully demonstrating its structure.

2. Manipulating various sensors and switches connected to the instrument system simulates the operation of the instrument signal source, realistically demonstrating the system's operation.

3. The teaching board panel is made of high-grade aluminum composite panel that is impact-resistant, stain-resistant, fire-resistant, and moisture-proof, with a special primer coating. Students can intuitively compare circuit diagrams and the actual device to understand and analyze the working principles of the automotive electronic instrument system.

4. The teaching board panel is equipped with test terminals, allowing direct testing of the electrical signals of various circuit components in the automotive electronic instrument system, such as resistance, voltage, current, and frequency signals.

5. The teaching board panel is constructed from 1.5mm cold-rolled steel sheet, resulting in an aesthetically pleasing appearance. The base is constructed of welded steel with a powder-coated finish. It features self-locking casters and a 40cm tabletop on the base for placing documents, lightweight testing instruments, etc.

6. The teaching board operates on standard 220V AC power, which is converted to 12V DC via internal circuitry. This eliminates the need for batteries, reducing charging inconvenience. The 12V DC power supply includes short-circuit protection.

Technical Specifications:

Dimensions: 1240 × 650 × 1700mm (L × W × H)

Operating Power Supply: AC 220V±10% 50Hz

Operating Temperature: -40℃ ~ +50℃
