PLC trainer with input output module

Electronic desk with ergonically designed ABS Molded enclosure with slick looking replaceable experimental panel

Can learn about different applications of Industrial PLC using replaceable static application panels (SAPs) & simulation cum extension panels (SEPs) SEPs to provide input switches, push buttons, O/PLED

Connection through sturdy 4mm Banana sockets & Patch cords.

Student's workbook & Instructor's Guide provided.

Power Supply: Built in SMPS Supply: 24V / 2 A

PLC used: S7 200 SMART Siemens

IO Specifications: 24DI + 16DO+ 4AI + 2AO

Programming Software: Required software should be supplied

Operating voltage: 110/220/230V ac, 50/60 Hz.

Mechanical Dimensions: 460 (H) x 160 (L) x 350 (D) mm

SEP FOR DIGITAL Input: No. of 4mm banana sockets =16. Consisting of 16 Nos. of Digital Inputs. (8 Slider switches + 8 push to ON switches).

SEP FOR DIGITAL Output: No. of 4mm banana sockets =20, 4mm shrouded sockets for relay contacts =8 Nos. 16 Nos. of Output LED Indicators, 4 Nos. of Relay Panel with coil rating 24V and contact rating of 220V AC / 5 Amp.

Baseboard Panel: Base board replaceable panel (215 x 165 x 40 mm) located in central slot. No. of 4mm banana sockets =32, consisting of 54 LEDs, with 10 LEDs for Bar Graph for AO.

Following Replaceable Static Application Panels should be supplied:

Door Bell Operation, Switching of Lights, Silo Control, 7 Segment Display, Starter Control, Sequential Control of Motors, Star Delta Control, Resistance Welding, Tank Level Control, Traffic Light Control, Bottling Plant, Drink Dispensers, Reaction Vessel, Micro-Wave-Oven, Car Parking Garage, Combination Lock, Elevator Simulator, Process Control Trainer and Washing Machine

Model: BOERBIDBD06-1

Brand: BOER

Country of Manufacture: China

Warranty: 2 (Two) year with services
