Dual-chamber brake master cylinder anatomical model

Product Overview:

The dual-chamber brake master cylinder dissected model is a teaching and training tool specifically designed for vocational schools majoring in automotive inspection and repair, automotive application and maintenance, and new energy vehicle technology. Based on the original mass-produced dual-chamber brake master cylinder, it is precisely manufactured to a 1:1 scale. Through professional dissection techniques, it fully presents the internal core structure, intuitively demonstrating the independent working principle and braking transmission logic of the dual chambers. It is suitable for courses such as "Automotive Braking System Structure and Repair" and "Automotive Chassis Structure," serving as a core teaching device for theoretical explanation, structural understanding, principle demonstration, and fault analysis.

Features:
1. Dissected using a complete dual-chamber brake master cylinder assembly (with all accessories), all components are included, comprehensively showcasing the assembly's internal and external structure.

2. Through dissection and different colors applied to each section, the mechanical structure of the internal and external components and their assembly relationships are clearly displayed.

3. The equipment base frame (with anti-vibration pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The anti-vibration pads are fixed to the base with M6*4 screws.

Training Projects:

I. Basic Training Information
Training Objectives:

To understand the components, cross-sectional structure, and independent dual-circuit hydraulic systems of a series dual-chamber brake master cylinder;

To master the workflow of normal braking and single-circuit failure (leakage in the front/rear chambers respectively);

To complete disassembly, assembly, inspection, and fault simulation diagnosis in a standardized manner, cultivating safe operation and teamwork skills.

Target Audience: Students majoring in automotive testing and repair, new energy vehicle technology, etc.

II. Modular Training Projects

Project 1: Structural Understanding and Principle Demonstration

Project 2: Standardized Disassembly, Assembly, and Cleaning Inspection

Project 3: Dual-Circuit Function and Failure Simulation Test

Project 4: Typical Fault Diagnosis and Troubleshooting

Project 5: Summary and Group Reporting
