Rotary pump anatomical model

Product Overview:

This product is a teaching-specific anatomical model designed for positive displacement rotary pumps (mainly cam/tri-lobe type). It is made to scale using a real pump body, preserving the core mechanical structure. Through precise cross-sections, color-coded sections, and a manually/electrically driven demonstration mechanism, it visualizes the core principles of the rotary pump's internal synchronous reverse rotor meshing, closed-chamber volume changes, and oil/liquid circulation. It is primarily used in vocational schools and skills training centers for theoretical and practical training in internal combustion engines, automotive chassis, agricultural machinery hydraulics, and industrial fluid transport courses. It can also serve as a pre-employment structural awareness training tool for new employees.

Features:
1. The model is a complete rotary pump assembly (with all accessories), showcasing all components and comprehensively displaying the assembly's internal and external structure.

2. Different colors are used for the cross-sections and sections, clearly revealing the mechanical structure of the internal and external components and their assembly relationships.

3. The equipment base frame (with shock-absorbing pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The shock-absorbing rubber pads are fixed to the base with M6*4 screws.

Training Project:
I. Basic Training Information
Training Name: Rotary Pump Anatomical Model Structural Cognition and Dynamic Demonstration Training
Applicable Majors: Automotive Inspection and Repair Technology, Engineering Machinery Application Technology, Electromechanical Equipment Repair, etc.

II. Training Objectives
Master the overall structure of the rotary pump, the names of its main components, and their assembly relationships.

Understand the working principle of the rotary pump's positive displacement pumping, and be able to describe the entire process of liquid suction and pressure.

Be able to independently perform manual driving, dynamic observation, and structural analysis of the rotary pump anatomical model.

Cultivate professional habits of standardized operation, parts management, and safe training.

III. Training Principle
The rotary pump is a positive displacement pump. Through the meshing rotation of the driving rotor and the driven rotor, the working volume within the pump chamber changes periodically, achieving liquid suction, sealing, transportation, and discharge. The anatomical model can intuitively demonstrate rotor meshing, changes in chamber volume, oil passage routing, and sealing structure, completely visualizing the internal, invisible movements.

IV. Training Content

(I) Structural Understanding and Static Observation

(II) Dynamic Demonstration and Principle Observation

(III) Disassembly and Assembly Training (Optional)

(IV) Fault Phenomenon Analysis (Training Extension)
