SCR trainer

SCR and GTO Circuits: SCR characteristics measurement and SCR phase angle control circuit

SCR/SCS/DIAC/TRIAC Application Circuits: SCR and SCS Application Circuit and DIAC & TRIAC application circuit

Function Generator and DC Power Supply:

Waveforms: Sine, Triangle, Square, TTL Pulse

Amplitude: 10Vpp

Impedance: 50Ω, ± 10%

Duty Control: 30% ~ 60%

Display: 6-Digit LED

Frequency Range: 10Hz ~ 100 kHz (4 Ranges)

Frequency Range: 100Hz ~ 1 MHz (4 Ranges)

Constant Voltage Output: ± 5V, ± 12V

Variable Voltage Output: 0V ~ ± 15V

Power source: 220~230V AC, 50Hz, 1 Phase

Accessories: Connecting cables, Short jumpers, Adapter and Instruction manual

Model: BOERBIDBD06-3

Brand: BOER

Country of Manufacture: China

Warranty: 2 (Two) year with services
