Variable Frequency Air Conditioner Training Equipment

OEM Accept OEM Accept ODM
Application Training Institute & School
Customization Size / Appearance / Material...
Function Automotive Training
Warranty 2 years
Package Wooden Box
Technical Support Software / Instruction manual / Video / Technician guidance
Shipping Way By Sea / Air / Express
Certification ISO9001 / GPSR / Copyrights

Overview
Recommended Products

I. Product Overview:
The panel is equipped with indicators for current, voltage, low pressure, high pressure, temperature, etc., to detect the circuit's operating status. The high and low pressure of the system are displayed via intelligent digital displays using pressure sensors with transmitter outputs. The control technology is advanced and highly integrated with automation.
1. Absolute circuit simulation (completely identical in overall structure and performance to variable frequency air conditioners on the market).
2. Multi-point temperature acquisition, cyclic detection, and digital display.
3. The air conditioner uses advanced pure DC inverter technology to save energy and facilitate teaching.

II. Composition:
Experimental table + power supply unit

III. Features:
Experimental table: Made of precision-machined steel with an overall epoxy polystyrene coating. The feet are equipped with casters with brakes for easy movement and fixation.
Power supply unit: The power control panel contains the power supply and DSP circuit boards, IPM intelligent power module, and indoor unit remote control circuit board from the variable frequency air conditioner.

IV. Technical Specifications:
1. Ambient Temperature: -5℃~40℃;
2. Relative Humidity: ≤90% (25℃);
3. Input Voltage: AC220V±5% (50Hz);
4. Maximum Current: 10A;
5. Equipment Weight: 130kg;
6. Cooling and Heating Capacity: Cooling 530K, Heating 600K;
7. Safety Protection: Leakage Protection (Leakage Operating Current ≤30mA, Operating Time ≤0.1s);
8. Refrigerant: F22;
9. Dimensions: 1600×860×1750mm;

V. Training Projects:
1. Module protection ;
2. Compressor top temperature protection ;
3. Outdoor temperature sensor open circuit;
4. Outdoor temperature sensor short circuit;
5. Cooling outdoor temperature too low;
6. Cooling outdoor temperature too high;
7. Indoor temperature sensor open circuit;
8. Indoor temperature sensor short circuit;
9. Condenser indoor unit coil open circuit;
10. Swing motor open circuit;
11. Indoor unit control board power transformer secondary open circuit;
12. Fan speed runaway;
13. Power fuse blown circuit protection;
14. Indoor unit and outdoor unit communication protection;
15. Ambient temperature sensor open circuit;
16. Ambient temperature sensor short circuit;
17. Coil temperature sensor short circuit;
18. Coil temperature sensor open circuit;
19. 5V voltage regulator open circuit;
20. Four-way valve wire;
