Analog Communication Trainer

Second order active low-pass filter (Low-pass-3dB frequency: 1kHz to 3 kHz)

Second order active high-pass filter (High-pass-3dB frequency: 5kHz to 10 kHz)

Second order active band-pass filter (Center frequency: 10kHz to 100 kHz, Bandwidth: 6kHz to 60kHz)

Second order active band stop filter (Cutoff frequency: 10kHz to 100 kHz, Bandwidth: 6kHz to 60kHz)

Colpitts Oscillator (Oscillation frequency: 1MHz to 9MHz)

Hartley Oscillator (Oscillation frequency: 500kHz to 1.8MHz)

Crystal Oscillator (Oscillation frequency: 6MHz)

Voltage Controlled Oscillator (Oscillation frequency: 3.5MHz to 4MHz)

Accessories: Connecting cables, Short jumpers, Adapter and Instruction manual
