Analog-Digital Trainer Board

Built-in regulated D.C. supplies: ± 18V, 1A Variable; + 5V ,1.0A; - 5V, 250mA

Function Generator: Sine wave: variable 0 to ± 4Vpp; Triangle wave: ± 4Vpp, Square wave: ± 5Vpp

Min 3 state logic probe

Two single shot pulse generators, 80μs

Min 8 Bit LED display with buffers

3.5 Digit Digital Voltmeter

Analog Current Meter: 0 to 1mA

2.5 inch 8 Ohm, 1W Loud Speaker

Min Two flip-flop gates with mimic diagram.

Input /Output connector, BNC & Banana

Min Two logic switches +5V/0V/ -5V with current limit

Min Eight data switches: +5V/0V

Two 25-Pin D-Type connectors for computer interface

Removable breadboard with 2230 interconnected tie-points, accepts 0.3-0.8mm solid wire

Standard accessories with printed operation manual
