Automatic load-adjusting brake energy distributor

Product Overview:

This product is a core intelligent braking component for commercial vehicles, construction machinery, and special vehicles. It integrates load sensing, pressure compensation, and energy distribution. Through mechanical or electronic closed-loop control, it dynamically matches braking force requirements under different loads, speeds, and road conditions, achieving optimal distribution of braking force between the front and rear axles and multiple axles, significantly improving braking stability, safety, and energy efficiency.

Features:
1. The automatic load-compensating brake energy distributor assembly (with complete accessories) is dissected, showcasing all components and providing a comprehensive view of the assembly's internal and external structure.

2. The dissection and different colors applied to each section clearly reveal the mechanical structure of the internal and external components and their assembly relationships.

3. The equipment base frame (with anti-vibration pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The anti-vibration pads are secured to the base with M6*4 screws.

Training Project:
I. Overall Training Objectives
1. To understand the core structure of the automatic load-compensating brake energy distributor, the functions of each component, and the installation and adaptation requirements.

2. Master the working principles and dynamic adjustment processes of its load sensing, pressure compensation, and braking force distribution.

3. Be able to perform standardized product disassembly and assembly, wiring (electronic version), parameter calibration, and daily inspection operations.

4. Be able to simulate common faults, analyze their causes, and complete fault diagnosis and repair, improving practical and diagnostic capabilities.

5. Understand the synergistic effect of this product in the braking systems of commercial vehicles and construction machinery, and establish an engineering mindset for safe braking.

II. Training Content
Project 1: Structural Cognition and Component Identification (Basic Required)

Project 2: Working Principle Demonstration and Observation (Basic Required)

Project 3: Standardized Disassembly and Assembly Training (Practical Required)

Project 4: Parameter Calibration and Adjustment (Electronic Version Specific)

Project 5: Daily Inspection and Maintenance Practice

Project 6: Common Fault Simulation and Troubleshooting (Core Practice)

Project 7: System Collaborative Application Training (Extension Project)
