Radar sensor training kit (laser, millimeter wave, ultrasonic)

Product Overview:

The experimental kit is based on the principles of intelligent connected vehicles, extracting ultrasonic radar, lidar, and millimeter-wave radar sensor modules to form functional blocks. The kit includes a complete set of experimental equipment, allowing for independent training and teaching of lidar and millimeter-wave radar experiments.

Features:
1. The system provides a user-friendly interface, allowing real-time modification of radar parameter settings and observation of debugging effects.

2. It can accurately identify static and dynamic obstacles, displaying data such as distance, speed, and position.

3. The x and y coordinates of the millimeter-wave radar can be set to calibrate external parameters, displaying the calibrated millimeter-wave detection image. Modifying the x and y coordinates shows the change of obstacles relative to the origin.

4. Detection results can be filtered for obstacles in desired areas by setting ROI regions.

5. LiDAR parameters, including Ethernet, time, and motor parameters, can be set via host computer software; the system receives lidar data streams and visualizes point clouds.

6. The external parameters (x, y, z) and pitch, yaw, and roll angles of the lidar can be calibrated by setting them via software.

7. Through the lidar perception algorithm control, by adjusting parameters such as detection range, filter threshold, and segmentation parameters, the point cloud recognition state can be changed, and obstacles can be marked, thus achieving an understanding of the lidar recognition algorithm; the true distance between obstacles and the test platform can be measured.

Training Projects:

1. Ultrasonic Lidar External Parameter Calibration

2. Ultrasonic Lidar Signal Analysis and Debugging Training

3. Millimeter-Wave Lidar Installation, Calibration, and Testing

4. Lidar Installation, Calibration, and Testing
