Planetary Dual Flywheel Anatomical Model

Product Overview:

This model is based on a planetary gear-type dual-mass flywheel. It features precise dissection of the actual assembly, visualized cross-sections, and retains the dynamic motion structure design. Specifically designed for courses on automotive chassis, automatic transmissions, and engine drive systems, it serves as a core training tool for integrating structural understanding, power transmission principles, and vibration damping mechanisms.

Features:
1. Dissects a planetary dual-flywheel assembly (with complete accessories), showcasing all components and comprehensively displaying the assembly's internal and external structure.

2. Through dissection and different colors applied to each cross-section, the mechanical structure of the internal and external components and their assembly relationships are clearly displayed.

3. The equipment base frame (with anti-vibration pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The anti-vibration pads are secured to the base with M6*4 screws.

Practical Training Projects:

I. Structural Cognition Training

II. Power Transmission and Working Principle Training

III. Relative Motion and Damping Characteristics Training

IV. Disassembly and Assembly Process Training

V. Fault Diagnosis and Analysis Training

VI. Comparative Teaching and Assessment Training
