Three-way catalytic converter anatomical model

Product Overview:

This product is a teaching dissected model specifically designed for vocational schools majoring in automotive testing and repair, and new energy vehicle technology. Based on a mass-produced original three-way catalytic converter, it realistically reproduces the internal structure, layers, and core components of the three-way catalytic converter through precise cutting, reinforced fixation, and high-gloss treatment of the cross-sections. Equipped with an adjustable demonstration system, it can intuitively demonstrate the catalytic principle and workflow of exhaust gas purification, making it a core teaching tool for theoretical teaching, practical training demonstrations, and skills assessment.

Features:
1. Uses a three-way catalytic converter assembly (with complete accessories) for dissection, with all components included, comprehensively showcasing the internal and external structure of the assembly.

2. Through dissection and different colors sprayed on each cross-section, the mechanical structure of the internal and external components and their assembly relationships are clearly displayed.

3. The equipment base frame (with shock-absorbing pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The shock-absorbing pads are fixed to the base with M6*4 screws.

Training Project:

I. Overall Training Objectives:

Knowledge: Master the structural composition of a three-way catalytic converter (shell, gasket, honeycomb carrier, catalytic coating, oxygen sensor interface, etc.), the oxidation-reduction reaction principle of exhaust gas purification, and understand the impact of air-fuel ratio and operating temperature on purification efficiency.

Skills: Accurately identify the components and assembly relationships of a three-way catalytic converter, master the exhaust gas purification process, simulate common faults and complete basic diagnosis and troubleshooting, and use training tools correctly.

Qualities: Adhere to training safety procedures, cultivate professional habits of data recording and process review, and improve teamwork and problem analysis abilities.

II. Core Training Modules:

Module 1: Structural Understanding and Component Disassembly

Task: Observe the cross-sectional structure of the three-way catalytic converter anatomical model, clarifying the shell, stainless steel interlayer, etc.

Module 2: Exhaust Gas Purification Principle Demonstration

Module 3: Fault Simulation and Diagnosis

Module 4: Performance Testing and Training Summary
