Starter motor dissected model

Product Overview:

This product is a dedicated teaching dissected model of an automotive starter motor. It is precisely modified from a real vehicle starter motor assembly. Through scientific cross-sectioning, color-coding, and dynamic demonstration design, it fully recreates the internal structure, working principle, and power transmission process of the starter motor. Specifically designed for teaching, practical demonstrations, structural awareness, and skills training in automotive electrical systems, it is suitable for various teaching scenarios such as vocational schools, training centers, and automotive repair training institutions. It can be directly used for teaching demonstrations, equipment tender documents, and product specifications.

Features:
1. The dissected model uses a complete starter motor assembly (with all accessories), showcasing all components and comprehensively displaying the assembly's internal and external structure.

2. Different colors are used for the cross-sections, clearly revealing the mechanical structure of the internal and external components and their assembly relationships.

3. The equipment base frame (with anti-vibration pads) is made of 1.5mm cold-rolled steel sheet, stamped and coated. The anti-vibration pads are secured to the base with M6*4 screws.

Practical Training Projects:

Project 1: Starter Motor Structure and Principle Explanation

Project 2: Standardized Disassembly and Assembly and Component Identification

Project 3: Electrical and Mechanical Testing of Key Components

Project 4: Dynamic Demonstration and Circuit Analysis

Project 5: Typical Fault Diagnosis and Troubleshooting

Project 6: Training Summary and Assessment
