Intelligent Connected Vehicle Simulation and Testing Training Platform

Product Overview:

A 1:1 scale replica of a real car cockpit, utilizing mainstream equipment such as servo motors, precision lead screws, and motion controllers, enabling smooth and rapid simulator movement and providing a realistic experience of centrifugal force, acceleration, shaking, and bumping.

Features:

The device can be linked with other test benches. In linked mode, the following functions are available:

1. Linkage with a drive-by-wire chassis training bench:

In autonomous driving mode, the intelligent connected vehicle simulation and testing training bench can control the drive-by-wire chassis bench to perform driving, steering, and braking actions. Simultaneously, the drive-by-wire chassis bench must synchronize its movements with the simulated car in the simulation bench, allowing for direct observation of the drive-by-wire chassis's driving status under the autonomous driving system's control.

In manual driving mode, the simulated car in the simulation bench can be controlled by the drive-by-wire chassis bench.

Compared to the functions of a real car, manually operating the drive-by-wire chassis bench can put the autonomous driving system into autonomous driving mode, taking over the drive-by-wire chassis bench and the simulated car in the simulation software.

2. Integration with Sensor Training Bench:

Utilize various algorithm software within the sensor training bench to perceive and identify various traffic participants in a virtual simulation scenario, conducting training in visual recognition, LiDAR recognition, and recognition fusion.

3. Integration with Intelligent Connected Vehicle Training:

Sensor data from the virtual simulation system can be output to the intelligent connected vehicle training, allowing for indoor testing of the vehicle's autonomous driving functions, serving as a prerequisite for real-world testing.

The intelligent connected vehicle simulation and testing training bench can control the drive-by-wire chassis of the intelligent connected vehicle, allowing participants to understand its working principles and drive-by-wire protocols, serving as a prerequisite for real-world testing.

Training Projects:

1. Autonomous Driving System Operation and Control Simulation Vehicle Training.

2. Steering Wheel Operation and Parameter Setting Training.

3. Joint Operation Training of Intelligent Connected Vehicle Drive-by-Wire Chassis and Autonomous Driving System.
